Tavoflex Swing Up Table Top Fit Aluminium Wht - Steel
Product Code: 643.12.201
Tavoflex Swing Up Table Top Fit Aluminium Wht - Steel
Product Code: 643.12.201
Out of Stock
Back in stock: 25/11/2026
£72.96
Ex. VAT: £60.80
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 1 | £72.96 | — |
| 2+ | £64.85 | Save 11% |
- Products Description
- Technical Specifications
- Dimensions
Article details
For moveable table tops with different effective heights and positions and access to storage space inside the tableEasy fitThe fitting raises the table top and swivels it sidewaysEasy to use from a seated positionSynchronising rods provide smooth movementThe lock safety catches on both sides prevents unintentional closingSide covers prevent fingers being trapped
The table top is lifted easily using gas filled strutsThe integrated soft closing mechanism provides gentle, silent closing
Area of application
For table tops, coffee tables and side tables up to a load bearing capacity of 5 kg
Version
With side finger protection
Recommended panel thickness
16 mm
Order reference
Order Varianta Ø 6 cylindrical head screws separately
Configuration required
Additional information attributes
Minimum gap to fixed table top 6 mm
For moveable table tops with different effective heights and positions and access to storage space inside the tableEasy fitThe fitting raises the table top and swivels it sidewaysEasy to use from a seated positionSynchronising rods provide smooth movementThe lock safety catches on both sides prevents unintentional closingSide covers prevent fingers being trapped
The table top is lifted easily using gas filled strutsThe integrated soft closing mechanism provides gentle, silent closing
Area of application
For table tops, coffee tables and side tables up to a load bearing capacity of 5 kg
Version
With side finger protection
Recommended panel thickness
16 mm
Order reference
Order Varianta Ø 6 cylindrical head screws separately
Configuration required
Additional information attributes
Minimum gap to fixed table top 6 mm
| Material | Steel |
| Load bearing capacity | 5 kg |
| Supplied with | 1 pair of swing-up table top fittings1 cross bar1 set of installation instructions |
| Installation | For screw fixing into pre-drilled 32 mm series drilled holes, installation of synchronising rod with size 6 Allen key |
| Installation width | 698 mm |
