Mitred Flap Hinge 135D for 45D App - Cup: Zinc Alloy, Hinge Arm: Steel Cup: Nickel Plated
Mitred Flap Hinge 135D for 45D App - Cup: Zinc Alloy, Hinge Arm: Steel Cup: Nickel Plated
Area of application
- For 45° mitre applications
- For door material: Wood
Material
- Cup: Zinc alloy, Hinge arm: Steel
- Colour/finish: Cup: nickel plated
- Opening angle: 135°
- For door thickness: 16 – 22 mm
- Side panel thickness: 16 – 20 mm
- Adjustment facility: Adjustable up to 3 mm in 3 directions
- Installation: For screw fixing
- Installation note: Provide 2 mm door gap all round.The edge must be chamfered by 3 mm from a side panel thickness of 20 mm.
Order reference
- Order Hospa Ø 3.5 mm raised head screws separately
The Mitred Flap Hinge 135D for 45D App (product code 325.00.708) is a Hafele engineered product built for dependable, precise performance in everyday use. Constructed from Cup: Zinc alloy, Hinge arm: Steel, it offers excellent resistance to wear and corrosion for long-lasting service in both professional and domestic settings.
Designed for simple installation with standard tools, this fitting is ideal for joiners, kitchen fitters, furniture manufacturers and builders. Order 325.00.708 from Essential Furniture Fittings for fast UK delivery.
Product Specifications
- Product Code
- 325.00.708
- Material
- Cup: Zinc alloy, Hinge arm: Steel
- Colour / Finish
- Cup: nickel plated
- Pack Quantity
- 1 Each
22 In stock
£24.73
Ex. VAT: £20.61
| Quantity | Unit Price (inc. VAT) | You Save |
|---|---|---|
| 1 – 4 | £24.73 | — |
| 5 – 9 | £23.42 | Save 5% |
| 10+ | £20.82 | Save 16% |
- Technical Specifications
- Dimensions
| Adjustment facility | Adjustable up to 3 mm in 3 directions |
| Area of application | For 45° mitre applications |
| For door material | Wood |
| Installation note | Provide 2 mm door gap all round.The edge must be chamfered by 3 mm from a side panel thickness of 20 mm. |
| Order reference | Order Hospa Ø 3.5 mm raised head screws separately |
| Material | Cup: Zinc alloy, Hinge arm: Steel |
| Colour/Finish | Cup: nickel plated |
| Opening angle | 135° |
| Installation | For screw fixing |
| For door thickness | 16 – 22 mm |
| Side panel thickness | 16 – 20 mm |
